MCAD software solutions developed by ASCON are famous for their powerful functions in the mid-range segment. They are easy-to-use with a comfortable interface, reasonable pricing, and strong compatibility with other systems.

KOMPAS-3D
base-program
KOMPAS-3D

KOMPAS-3D is intended for creating three-dimensional associative models for individual parts and assembly units containing both original and standardized structural elements. The parametric technology allows quickly to obtain models for typical products basing on a once designed prototype.

A key feature of KOMPAS-3D is the use of its own mathematical core and parametric technologies developed by ASCON specialists.

KOMPAS-3D Viewer
base-program
KOMPAS-3D Viewer

The KOMPAS-3D Viewer is a utility program that allows you to view and print drawings and model templates created by KOMPAS-3D, as well as files saved in DWG and DXF formats.

3D-Storage
add-on pack
3D-Storage

3D-Storage is a system for data storage and collaboration of engineers.

The tool serves for the arrangement of the collaboration of designers with models, drawings, specifications of KOMPAS-3D and other CAD at the development stages: technical proposal, sketch design, technical design, detail design documentation of prototype, i.e. before the generation of the engineering bill of material. Companies can use the system to set up remote mode of work.

Materials Library
add-on pack
Materials Library

Material library is database of information about materials that are used to manufacture products. Materials Library applies physical and mechanical material properties to 3D models designed in KOMPAS-3D.

An object of this Materials library is a material, shape, processing, document that defines requirements to an object or its properties, assortment, assortment example.

Standard Parts Catalogue
add-on pack
Standard Parts Catalogue

Standard Parts library contains standard parts according to DIN and ISO standards.

The catalogue contains 3D models and 2D drawings of standard parts and structural elements both for KOMPAS-3D and KOMPAS-Graphic.

3D shafts & mechanical gears
add-on pack
3D shafts & mechanical gears

Automate the design and construction of three-dimensional models of shafts, bushings and mechanical transmission elements in the KOMPAS-3D environment. Enables fast construction of multistage shafts, including structural elements such as grooves, holes, splines and keyways.

Cable 3D
add-on pack
Cable 3D

Design System "Cables and Harnesses" is a specialized Add-on for electrical cables and harnesses modelling in KOMPAS-3D.

Mechanics: Spring
add-on pack
Mechanics: Spring

The application allows you to perform design and verification calculations of compression, tension, torsion springs, as well as Belleville, conical and shaped springs. Based on the calculation results, drawings and 3D models are automatically generated

Pipelines 3D
add-on pack
Pipelines 3D

Pipelines 3D is a specialized application for KOMPAS-3D software; it is intended for automation of routine works on pipelines design.
The library is intended for using in the machine building area and for designing utility networks.
The application can use components manually created by user and components from Standardized Parts catalogues as standard pipeline’s components.

Steel Structures 3D
add-on pack
Steel Structures 3D

The Steel Structures 3D is a specialized application for KOMPAS-3D software. It is intended for automation of design process of metal constructions from metal rolling profiles. The library is intended for using in the machine building area and for designing steel frameworks.

The Steel Structures 3D application allows create frameworks on the basis of trajectories and the selected profiles. Profiles can be selected from template container. The structure’s position can be set or modified.
